China Low Temperature Oil Ethanol Extraction Filter Centrifuge

Looking for a reliable China Low Temperature Oil Ethanol Extraction Filter Centrifuge supplier? We are a factory specializing in high-quality extraction equipment.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Product Features
  • Packaging & Shipping
  • Company Profile
  • After Sales Service
  • FAQ
Overview

Basic Info.

Model NO.
PPTD-30
Max Speed
1000r / Min
Product Name
Oil Ethanol Extraction Filter Centrifuge
Diameter(mm)
450
Capacity(L)
20
Max Load(Kg)
30
Motor(Kw)
1.5
Weight(Kg)
300
Transport Package
Packed in Strong Wooden Case
Specification
2450 *1700 *1675 mm
Trademark
ZZKD
Origin
China
HS Code
8421192000
Production Capacity
300sets/Month

Product Description

China Low Temperature Oil Ethanol Extraction Filter Centrifuge
Product Description

Basket centrifuges are often called centrifugal filters or clarifiers. They have a perforated wall and cylindrical tubular rotor. In many cases the outer wall of a basket centrifuge consists of a fine mesh screen or a series of screens with the finer mesh screens supported by the heavier coarse screen, which in turn is supported by the bowl. The liquid passes through the screen and the particles that are too large to pass through the screen are deposited. Main purpose of ZZKD brand centrifugal extraction equipment is to extract from dried hemp and filter out the organic matter and plant debris that are insoluble in ethanol. Centrifuge is the most convenient ethanol extraction solution in extracting industrial hemp. The material is quickly extracted by full contact with ethanol and high speed rotation.

China Low Temperature Oil Ethanol Extraction Filter Centrifuge China Low Temperature Oil Ethanol Extraction Filter Centrifuge China Low Temperature Oil Ethanol Extraction Filter Centrifuge China Low Temperature Oil Ethanol Extraction Filter Centrifuge China Low Temperature Oil Ethanol Extraction Filter Centrifuge China Low Temperature Oil Ethanol Extraction Filter Centrifuge China Low Temperature Oil Ethanol Extraction Filter Centrifuge
Model PPTD-10 PPTD-30 PPTD-50 PPTD-135 PPTD-200 PPTD-400 PPTD-500
Drum capacity (L) 14 40 85 185 295 450 510
Jacket volume (L) 22 30 43 75 110 150 155
Loading limit (lbs) 15 60 120 270 500 940 1060
Plant material loading limit (lbs) 4 16 30 70 100 180 240
Speed (R/ min) 2700 1900 1500 1200 1000 960 960
Separation factor (g) 1225 910 755 645 560 620 645
Motor (kW) 1.1 1.5 3 5.5 7.5 15 18.5
Frequency converter (kW) 1.5 2.2 4 7.5 11 18.5 22
Net weight (kg) 280 400 750 1700 2350 3100 3350
Drum diameter (mm) 300 450 600 800 1000 1200 1250
China Low Temperature Oil Ethanol Extraction Filter Centrifuge
Product Features

Solid-Liquid Semi-Automatic Machine Centrifuge. The motor drives the basket to rotate at high speed through the belt, and under the control of pre-written program, the material to be separated is fed into the basket through the feed system. After the material is filtered through the filtration medium (filter cloth/screen) under the action of centrifugal force, the liquid phase discharges out of the centrifuge through the liquid pipeline, and the solid phase is retained in the basket. A material detection device is used to detect material filling position in a real-time manner, and when the solid cake deposited in the basket reaches the specified holding capacity of the centrifuge, feeding stops. Then wash and dry the solid cake. After the solid cake meets the requirements for knock-out, the centrifuge reduces the scraping rate, under the hydraulic (pneumatic) control, the scraper device removes the solid cake, and then the cake is discharged at the bottom outlet of the centrifuge.

China Low Temperature Oil Ethanol Extraction Filter Centrifuge
Packaging & Shipping


China Low Temperature Oil Ethanol Extraction Filter CentrifugePackaging:
-After use cartons inside, outside with wooden case packaging;
-Both neutral and customized packaging can be available.

Shipping:
-We can ship the goods to you by International Express such as DHL, TNT, EMS, FedEx and so on and you can also choose the appropriate one based on your timeline and budget. Besides, you can definitely choose to use your own shipping agent.

Shipping method Note
Express Door to door, very convenient, don't need to clearance or pick-up
By air Airport to an airport, you need to do the customs clearance and pick up the goods at your local airport, which you can have a local shipping agent to do for you.
By sea Port to port and you need to do the customs clearance and pick-up the goods at your local port, which you can have a local shipping agent to do for you.

Company Profile

Zhengzhou Keda Machinery and Instrument Equipment Co., Ltd. is specialized in R & D, production, sales, teaching, and chemical biology pharmacy equipment integrated company. The main products are rotary evaporator, jacketed glass reactor, single layer glass reactor,circulating water vacuum pump, low-temperature reaction bath (slot), low temperature cooling fluid circulating pump(cool chiller), vacuum drying oven, blast drying oven, freeze dryer, water/oil bath, magnetic heating stirrer,overhead mixer, ultrasonic cleaning machine, lift platform, etc. Besides, we act as agents of some domestic and foreign famous enterprise products, sustaining high praise in domestic junior colleges and universities, scientific research units, etc. Our products are sold in the USA, Australia, Asia, Brazil, Iran, Egypt, etc. countries and our customers have been fully affirmation.

Factory Size: 1,000-3,000 square meters
Year Established: 2009
Total Revenue: US$1 Million - US$2.5 Million
Registration No.: 410105000067362
Main Markets: Central America, Mid East, Oceania, Africa, South America
China Low Temperature Oil Ethanol Extraction Filter Centrifuge

After Sales Service

Pre-sale Service:
--24 Hours online service for your consult.
--Help choose the right model, and a series of services, person, and advice.
--Give you the best offer.
--Provide discount for many sets order.
--Do customer's request.
--Choose payment term you convenient.
--Promptly production and delivery, inform you in time.
--Can provide invoice value as you like to decrease your tax.
After-sale service:
--1 year warranty service and all life maintenance.
--Technical Engineers are available for oversea training.
--Remote control technical consult.
--Free installation DVD.
--Maintenance plan.



FAQ

1. What's the minimum order quantity?
One set at present.

2. What kind of payment terms do you accept?
Normally we accept TT, Paypal, Western Union, Alibaba Escrow, and L/C. The exact term will be discussed during the deal.

3. How will you deliver these goods?
It will be decided according to your quantity. Normally we will choose International Express, Air and sea.

4. How will package glass equipment be?
We package these glass equipment in good and Nonfumigation standard wooden cases.

5. Can you accept OEM terms?
Sure.

6. How to choose suitable equipment?
You tell us your requirements (For example capacity, temperature range, pressure, etc ), we will recommend you the best suitable equipment.

China Low Temperature Oil Ethanol Extraction Filter Centrifuge
China Low Temperature Oil Ethanol Extraction Filter Centrifuge
China Low Temperature Oil Ethanol Extraction Filter Centrifuge
