Milk processing evaporator Milk processing equipment

Discover the efficiency of our milk processing evaporator and equipment. As a factory, we ensure top-notch quality for all dairy processing needs.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Company Profile
  • Our Service
  • Trade shows
  • Certificate
  • Packaging & Shipping
  • FAQ
Overview

Basic Info.

Model NO.
BEYOND
Power Source
Gas
Automatic Grade
Automatic
Name
falling film evaporator
Material
SUS304
Suggested power
20kw~35kw
Machine type
Three-stage falling film downstream evaporator
Steam consumption
1600kg/h
Evaporating capacity
4T/h
Transport Package
Wood Case
Specification
customized
Trademark
Beyond
Origin
Shanghai-China

Product Description

Milk processing evaporator Milk processing equipment
Milk processing evaporator Milk processing equipment


Two effect evaporator:this equipment adopts two effect falling film to evaporate the water in the milk and fruit juice;
Construction:evaporator,separator,condenser etc.
Use:popularly used for concentrating and dehydration in food,biology engineering,pharmacy and chemistry etc.
Automatic control:manual operated and full auto control;

Characteristics
1,Adopts twin effect type,high use factor of steam,low energy consumption;
2,Full closed process,fast and low temperature evaporation,so the nature color and flavor and smell is well remained.
3,Heating fast with high efficiency and strong capability of anti-scaling.
4,Large scale of the concentrate rations the products between the different effects can recycle separately,so the concentrate ratio can be regulated in large scale.



Milk processing evaporator Milk processing equipment



Technical parameter



Model
Evaporation capacity of water
External dimension
(L×W×H)
Steam consumption
(kg/h)
power
JNS-2-0.8
≤0.8(T/H)
4500*2500*7000
≤0.45(T/H)
20
JNS-2-1
≤1(T/H)
4500*2500*7200
≤0.55(T/H)
22
JNS-2-1.5
≤1.5(T/H)
4800*3000*7600
≤0.8(T/H)
30
JNS-2-2
≤2(T/H)
4800*3000*7800
≤1.1(T/H)
30
JNS-2-3
≤3(T/H)
4800*3200*7800
≤1.65(T/H)
35



Technical parameters (evaporation according to the customer need to design)


    Condition: New
Brand name: Shanghai Beyond;
Type: whole processing Line/turnkey project/fruit and vegetables processing/dairy processing/beverage processing
Voltage: 220v/380v
Power(W): 100-200kw
Weight: Different size different weight/customized
Dimension(L*W*H): Different size different dimension/customized
Certification: CE&ISO
Warranty: 12 months/1 year
After-sales Service Provided: Engineers available to service machinery overseas
Main material: SUS304 or SUS316
Control type: automatic, semi-automatic
energy consumption: Low consumption with high efficiency
capacity: 500-10000L/H-customized
installation period: 1-3months

Period time: 30 days-120 days
Cups material: pouches, paper box, glass bottle, pet bottle, glass bottle

Product storage condition: room temperature; low temperature;

Related machinery of fruit processing line
Fruit storage silo-- Washing, sorting machine-- Grading/classifier machine
Squeeze extractor--Juice refiner-separator-evaporator-- Juice concentrate product
Fruit flesh/pulp collector-sterilizer--filling machine-fruit flesh
Essential oil refiner-fruit oil
Fruit residues collector-animal feed
Soaking extraction, pre-cooking, pulping, quick freeze, stemmer, ultra-filtration, decolor, destoner, crusher, stone washer, brusher washer, pine apple extractor, refiner, enzymolysis, filtration, CIP cleaning system


Milk processing evaporator Milk processing equipment Milk processing evaporator Milk processing equipment




Company Profile

Milk processing evaporator Milk processing equipment



Milk processing evaporator Milk processing equipment



Milk processing evaporator Milk processing equipment

Our Service
Milk processing evaporator Milk processing equipment




Trade shows




Milk processing evaporator Milk processing equipment

Certificate



Milk processing evaporator Milk processing equipment





Packaging & Shipping



Milk processing evaporator Milk processing equipment








FAQ



1 ) Q: How can we visit your factory?
A: If you come from abroad, air to shanghai airport, then we can pick you up at airport.



2) Q: How do you ensure the quality of your products?
A: Our Company is a state owned enterprise with more than 16 years experience , strict operation policy is performed, advanced processing machines guarangtee the precision of all components, workers with operation license, parts get multiprocessing, transmission& electrical parts are of international famous brand. Series of test and inspection are done in the whole producing state.



3) Q: What payment methods your company accept?
A: We accept most of the payment methods , but mainly accept T/T, L/C at sight .



4) Q: How long is the warranty time for your products?
A: Our officially promised warranty time is 12 months after commissioning .



5) Q: I am new in this field,can you supply us turnkey services?
A: YES.We can supply all the system including Market Analysis/Product Analysis/Location Choice/Processing Flow Design/Equipment Layout Design/Building Design direction/Equipment mode selection/Equipment Manufacturing/Equipment Mounting/Equipment Debugging/Worker Training.



6) Q: What ' s the shipment terms and delivery time of your company?
A: Well, the delivery time depend on the quantity of your order. Usually is 20 days . For some customized machine 30 days is necessary.



7) Q: Can you supply OEM services?
A: Yes,we have our R&D team,and we have more than 400 workers with workshop area 75000 square meters.



8) Q: Do you give any Discount?
A: I will surely try my best to help you get those by the best price and good service at the same time.
