Sour Gas H2s Removal Process Iron Hydroxide Solid H2s Absorber

IronHydroxide Solid H2S Absorber effectively removes sour gas H2S in a cost-effective manner. Our factory produces high-quality products for gas processing.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
Iron Oxide Iron Hydroxide H2s Adsorbent
Application
H2s Removal
Gas Streams
Natural Gas, Shale Gas, Biogas, Oil and Gas
Transport Package
Bag and Tray
Specification
800kgs/ bag
Trademark
Mingshuo
Origin
China
HS Code
3824909990
Production Capacity
10, 000 Ton/ Year

Product Description

Sour Gas H2s Removal Process Iron Hydroxide Solid H2s Absorber

Sour gas H2S removal process iron hydroxide solid h2s absorber


Hydrogen sulfide is an inorganic compound with a chemical formula of H2S. Normally, it is a colorless, flammable acid gas. Hydrogen sulfide is naturally found in crude oil, natural gas, volcanic gases, and hot springs.

It's flammable, toxic to the human body, polluted to the environment, and corrosive to metal equipment, so it must be removed from gas streams, such as biogas, natural gas, shale gas, oilfield associated gas, tail gas, flue gas and etc.

MT series iron oxide desulfurizer is mainly used in hydrogen sulfide containing water gas, semi-water gas,
coke oven gas, natural gas, liquefied gas, waste gas and oilfield associated gas for the industries of biogas,
city gas, fertilizer, coking, citric acid, winery, metallurgy, textile, light industry, electronics and
environmental protection etc. This series of products also has the characteristics of simple equipment,
convenient operation, strong adaptability and small bed resistance.

It's characterized by a high degree of purification and high intensity. Moreover, it won't become clay with water, so widely used in natural gas, oil field gas, methane gas, coke oven gas, semi water gas, water gas and other gases in the removal of hydrogen sulfide.

Sour Gas H2s Removal Process Iron Hydroxide Solid H2s Absorber
Main physical and chemical indicators
Granularity (mm) Breakthrough sulfur capacity (%) Intensity (N/cm) Bulk density (g/L) Specific surface area (m2/g) Pore rate (%)
φ4-5, L3-15 12-20 ≥50 0.70-0.85 70~80 50~70

Operation conditions and notes
1) Airspeed: 200-1500h-1
2) Temperature: 10-80 centigrade
3) Pressure: Up to 8MPa

Working principles
Fe2O3 · H2O + 3H2S = Fe2S· H2O + 3H2O
FeOOH +2H2S = FeSSH + 2H2O

The H2S is changed chemically through an environmentally friendly reaction resulting in a non-hazardous solid waste and water. No negative residual chemistry / compounds in the gas stream to cause scaling, foaming or block downstream equipment.


Sour Gas H2s Removal Process Iron Hydroxide Solid H2s Absorber

Management System Certification: ISO9001:2008, ISO14001:2004, OHSAS18001:2007

Sour Gas H2s Removal Process Iron Hydroxide Solid H2s Absorber
Company Introduction:
Founded in 2004, Shandong Mingshuo New Energy Technology Co., Ltd. is located in Shandong Province, China. With a registered capital of CNY 88 million and an area of over 16 acres, Mingshuo is dedicated to the development, manufacturing, sales and service providing in environmental protection field.

We mainly specialize in organic waste treatment, biogas plant, desulfurization system, biogas purification, biogas utilization and organic fertilizer systems. As the production base of medium and large biogas equipments in China, our company is highly recommended by China Biogas Association, China Association of Rural Energy Industry, and China Import and Export Commodity Website. Our company has passed the quality management system ISO 9001:2008, environment management system ISO 14001:2004 and occupational health & safety management system OHSAS 18001:2007 standards, with professional environmental engineering construction qualification, safety production license in construction field, and qualifications of Class D1, D2 pressure vessel. Moreover, we have obtained more than 30 patents and participated in the formulation of the national standards for biogas desulfurization equipment.
Sour Gas H2s Removal Process Iron Hydroxide Solid H2s Absorber

With the unique design, professional R & D team, and pursuit of better solution, we're able to offer the most suitable and customized professional technical consulting, technical supports and after-sale services for all types of customers according to their different requirements and situations. Our products are widely used in biogas, fertilizer, coking, natural gas, city gas, food, ceramics, and other industries.

Sour Gas H2s Removal Process Iron Hydroxide Solid H2s Absorber
Sour Gas H2s Removal Process Iron Hydroxide Solid H2s Absorber
